Powering next-gen emissions diagnostics with compliance, performance, and flexibility.
Overview
Package
- DCM: ISO 15031-5 Services
- DEM: Fault Handler or Fault Memory to support OBD
- FIM: Inhibition Control for SW Modules
- CANTP: ISO 15765-4 Transport layer
Advantages
- OEM-agnostic AUTOSAR-compliant solution
- Easily customizable to meet specific OEM requirements
- Generates optimized and ready-to-integrate application code templates
Product Description
With the shift towards zero-emission vehicles, Onboard Diagnostics (OBD) have become crucial. They monitor and observe the characteristics of a vehicle’s emissions. In simple terms, if ECUs are emission-relevant, they must support OBDs for a sustainable future. In the last few years, the OBD regulations have changed and now require emission-relevant diagnostics support across a broader range of ECUs.
ElectRay’s eSAR.OBD stack compliance with ISO 15031-5 standard and is AUTOSAR R4.4.0 compliant. You can use this stack for automotive, commercial vehicles, three-wheelers, and two-wheelers, supporting the latest industry requirements for emissions-related diagnostics.
The stack includes integrated support for:
- Emission-related Diagnostic Trouble Codes (DTCs)
- Fault memory management
- Permanent and pending fault tracking
Designed with flexibility in mind, eSAR.OBD can be deployed in both AUTOSAR Classic and non-AUTOSAR (legacy) ECU platforms. Its scalable architecture and low memory footprint make it ideal for integration into resource-constrained ECUs.
ElectRay’s eSAR.OBD stack empowers OEMs and suppliers to meet global OBD compliance requirements efficiently, while maintaining high levels of reliability, scalability, and system performance.
Specification
- Key Supported Diagnostic Services: $01, $02, $03, $04, $06, $07, $08, $09, $0A
- AUTOSAR R4.4.0 Compliance
- ISO 15031-5 Compliance
- MISRA compliant
- Configuration tool to configure the stack
- ANSI C source code
- Fault logging and storage
- Perform fault analysis
- Can be used with or without RTOS
- Due to AUTOSAR Architecture, highly configurable and scalable
Additional Details
Supported Platforms
Platform Independent
Post Sales Support and Services
- Support for integration and customization as per your ECU platform.
- Tailored stack configuration to meet specific OEM requirements
